Descrizione

Telecamera BOX analogica di elevata qualità ed ottimo e potente zoom fino a 39x. Adatta a contenitori stagni e speed dome con telecamera intercambiabile. Dotata anche di telecomando radio per poter gestire lo zoom.

Specifiche Tecniche

1/4″ Sony Super HAD CCD
39X Optical Zoom
800 TV Lines
OSD Menu / Line control / RS – 485 Control
Auto focus
Auto electric shutter
Automatic backlight compensatory function
Automatic tracking white balance

Technical Information:
Image Sensor : 1/4″ SONY Super HAD CCD
Zoom Lens : 39X (3.9mm – 102mm)
Effective Pixels :
– PAL : 500 (H) x 582 (V)
– NTSC : 752 (H) x 582 (V)
Focus : Auto / Manual / Auto Key Control
Iris : Auto
Horizontal Resolution : 800TVL
Minimum Illumination : 1.0 LUX / F1.2
Electronic Shutter :
– PAL : 1/50 – 1/100,000 SES
– NTSC :1/60 – 1/100,000 SES
Scanning System : PAL / NTSC
Viewing Angle (Horizontal) : Approx. 52° ± 2°
Viewing Angle (Vertical) : Approx. 42° ± 2°
S/N Ratio : >48dB
Video Output : BNC connector, 1Vp-p / 75Ω
White Balance : Auto
Gamma Correction : >0.15
Protocol : PELCO-P / PELCO-D
Baud rate : 2400 / 4800 / 9600 bps
Control Method : OSD Screen Menu / Line Control / RS-485 Control
Body Material : Aluminum alloy
Camera Dimensions : approx. 110 (W) x 68 (H) x 63 (D) mm
Bracket Height : approx. 8cm
Operation Temperature : -10° C ~ 50° C
Power Supply : DC 12V, 1000mA
